产品说明
一般描述
For precise flow-monitoring of liquids and gases. Clear PC safety shield permits use at high temperatures and pressures. Fluid contacts PTFE body, borosilicate glass tube, Viton® O-rings, and floats (glass, 316 SS, or ruby).
NPT-male end bushings are PP with PTFE inserts that accept flexible hose. For high-purity applications, order PTFE coupling adapters to prevent fluids from contacting the bushings.
Extremely accurate: ±2% of the reading or ±1% scale division. Calibration table for air and water included with each flowmeter.
Accepts 3/8 in. I.D. tubing (sizes 4 and 5 accept min. 5/8 in. I.D. tubing).
Note: Flow rates are at standard temperature and pressure (20℃ and 14.7 psi).
法律信息
Gilmont is a registered trademark of Gilmont Instruments, Inc.
Viton is a registered trademark of E. I. du Pont de Nemours and Company
基本信息
| NACRES | NB.51 |
产品性质
| 管尺寸 | 5 |
| manufacturer/tradename | Gilmont EW-03205-20 |
| flow rate measuring range | 3,000-77,000 mL/min (air, glass float) 30-1,900 mL/min (water, glass float) 36,000-137,000 mL/min (air, SS float) 64-4,100 mL/min (water, SS float) |
| 参数 | ≤50 psi pressure |
| 长度 × 外径 | 13 1/4 in. × 1 1/2 in. |
| 衬管NPTM | 1/2 in. |
