位置:首页 > 品牌 > Sigma-Aldrich > 聚(3,4-乙烯二氧噻吩)-聚(苯乙烯磺酸酯)

Poly(3,4-ethylenedioxythiophene)-poly(styrenesulfonate)

聚(3,4-乙烯二氧噻吩)-聚(苯乙烯磺酸酯)

品牌
Sigma-Aldrich
货号
900208
规格纯度
dry re-dispersible pellets, high conductivity
参考价格
1582.23 *本价格含增值税费
促销
服务
  • 原厂保证
  • 包邮
  • 增值税票
数量
-+
产品名称:
Poly(3,4-ethylenedioxythiophene)-poly(styrenesulfonate)
Poly(2,3-dihydrothieno-1,4-dioxin)-poly(styrenesulfonate)
PEDOT:PSS
Orgacon DRY5
聚(3,4-乙烯二氧噻吩)-聚(苯乙烯磺酸酯)
聚(3,4-亚乙二氧基噻吩)-聚(苯乙烯磺酸)
产品介绍:

产品说明

一般描述

Poly(3,4-ethylenedioxythiophene)-poly(styrenesulfonate) (PEDOT:PSS) (dry re-dispersible pellets) is a conductive polymer that is formed by electropolymerizing 3,4-ethylenedioxythiophene in a solution of poly(styrenesulfonate)(PSS). PEDOT is doped with positive ions and PSS with negative ions. It has the following properties that make it viable polymer in organic electronics:

  • low band gap
  • good optical properties
  • high conductivity
  • low redox potential
  • easy processing
  • tunable film forming ability

应用

Orgacon DRY5 pellets can be re-dispersed in organic solvents such as ethanol. The resulting dispersion can be used in coating or ink formulations targeted for different applications requiring high conductivity.
PEDOT:PSS can be used as an electrode material with high mobility for charge carriers. It can be used for a wide range of energy based applications such as organic photovoltaics (OPV), dye sensitized solar cells (DSSCs), organic light emitting diodes (OLEDs), supercapacitors and other biomedical based sensors.
几乎 100% 吸收波长为 900-2,000nm 的光。对波长为 400-800nm 的光不具有最大吸收。共混导电聚合物。

包装

1 g in poly bottle

法律信息

Orgacon is a trademark of Agfa-Gevaert N.V.

基本信息

MDL编号MFCD07371079

产品性质

质量水平100
形式pellets
薄层电阻<200 Ω/sq (by addition of 5% diethylene glycol)
储存温度2-8℃

安全信息

象形图GHS05
警示用语:Danger
危险声明H314
预防措施声明P260 - P280 - P303 + P361 + P353 - P304 + P340 + P310 - P305 + P351 + P338 - P363
危险分类Eye Dam. 1 - Skin Corr. 1B
储存分类代码8A - Combustible, corrosive hazardous materials
WGKWGK 3
闪点(F)Not applicable
闪点(C)Not applicable
