产品说明
一般描述
Roll-to-roll, high-quality, monolayer CVD graphene with large grain size (∼110μm2) on copper foil, A5 size.
应用
Our Roll-to-Roll CVD graphene products are true monolayer high quality graphene, fabricated inside a Cleanroom, heavily monitored and QC to assure high reproducibility.
The roll-to-roll process allows continuous, large scale graphene production.
This large grain size product with low sheet resistance would enable unmatched reproducibility and allow high performance for CVD graphene based FET, CVD graphene based sensors, and heterostructure based micro/nano electronics.
Application examples:
注意
Be cautious not to drop
Keep away from contamination, heat, dust and flame etc.
储存及稳定性
Avoid direct sun light, avoid high temperature, avoid high humidity, and avoid dust.
法律信息
Product of LG Electronics, R&D use only
基本信息
| 线性分子式 | C |
产品性质
| 质量水平 | 100 |
| 描述 | Growth method: roll-to-roll CVD Raman intensity 2D/G: ≥1.5 Number of layer: Monolayer |
| 薄层电阻 | 280 Ω/sq ±10% |
| 尺寸 | 110 μm × 110 μm ± 10%, grain size |
| 厚度 | 35 μm , Cu Foil |
| 表面覆盖度 | surface coverage >98% |
| 透射比 | >97% |
| 半导体性质 | (mobility>3000 cm2/V·s) (Hall effect measurements) |
安全信息
| 象形图 |  |
| 警示用语： | Warning |
| 危险声明 | H410 |
| 预防措施声明 | P273 - P391 - P501 |
| 危险分类 | Aquatic Acute 1 - Aquatic Chronic 1 |
| 储存分类代码 | 13 - Non Combustible Solids |
| WGK | WGK 3 |
| 闪点(F) | Not applicable |
| 闪点(C) | Not applicable |
