IKA^® MF 10.2 impact grinding head

产品说明

一般描述

IKA^® MF 10.2 Impact Grinding Head
For crushing brittle, hard materials such as minerals, building materials up to Mohs hardness 6. Before being discharged, the ground material passes through a sieve. This sieve is interchangeable and available in different hole sizes (not incl. with delivery). The ground material can then be collected using an NS 29 standard ground vessel.

• Process type: inline
• Circumferential speed max.: 31.4 m/s
• Feed hardnessmax.: 6 Mohs
• Feed grain size max.: 10 mm
• Material milling chamber: stainless steel 1.4308
• Milling chamber, can be cooled with water: no
• Mill feed can be cooled in milling chamber with dry ice: yes
• Mill feed can be cooled in milling chamber with liquid nitrogen: no
• Dimensions (W x H x D): 320 x 450 x 300 mm
• Weight: 2.7 kg

法律信息

IKA is a registered trademark of IKA-Werke GmbH & Co. KG
