Flexmark 9 TPU flexible 3D printing filament

产品说明

一般描述

TPU Flexible 3D Printing Filament

• TPUs are highly resistant to chemical agents, wear-proof and have good elastic comeback.
• Flexmark 7 = 70 Shore A, the most flexible, but it requires a precise calibration of the printer.
• Flexmark 8 = 80 Shore A, a good mixture of flexibility and stiffness and easier to print.
• Flexmark 9 = 90 Shore A, the stiffest of all the Flexs and lets you print as usual.

• Density: 1.24 g/cm3
• Hardness: 93 sh/A
• Elongation at break: 600%
• Tensile strain: 55 MPa
• Compression set at 70 ℃: 45%
• Charpy Impact at 23 ℃: No break
• Charpy Impact at -30 ℃: No break
• Abrasion loss: 30 mm3

应用

Flexmark 9 TPU 3D Printing Parameters

• Extruder (nozzle) temperature: 225 +/-10 ℃
• Bed temperature: cold to 45 ℃
• Print speed: 25-35 mm/s
• Fan: 0-50 %
• Minimum nozzle diameter: 0.3 mm
• Plate materials: glass, blue tape, kapton tape, etc.
