Optiscale<SUP>®</SUP>囊式过滤器(Durapore)<SUP>®</SUP>

产品名称：

Optiscale^® Capsule Filter Durapore^®
Optiscale Durapore 0.22 μm 3/4 in. TC-1/4 in. HB
Optiscale^®囊式过滤器(Durapore)^®

产品介绍：

产品说明

一般描述

Device Configuration: 取样皿滤膜

其他说明

These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Directions for Use

Organism Retention: Bacterial
Mode of Action: Filtration (size exclusion)
Application: Protein purification
Intended Use: Reduction or removal of microorganism/bioburden
Instructions for Use: Please refer installation and wetting sections of OPTISCALE^®-25 user guide
Storage Statement: Please refer OPTISCALE^®-25 user guide
Disposal Statement: Dispose of in accordance with applicable federal, state and local regulations.

制备说明

Sterilization Method
3 autoclave cycles of 60 min @ 126 °C

分析说明

Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥100 mL

法律信息

Durapore is a registered trademark of Merck KGaA, Darmstadt, Germany
OPTISCALE is a registered trademark of Merck KGaA, Darmstadt, Germany

基本信息

eCl@ss	32031610
NACRES	NB.24

产品性质

物料	PVDF membrane PVDF vent cap fluoroelastomer FKM seal polycarbonate polypropylene support
质量水平	400
reg. compliance	meets FDA Indirect Food Additive requirements cited in 21 CFR 177-182 (all component materials)
无菌性	sterile
特点	hydrophilic
manufacturer/tradename	OptiScale^®
参数	25 ℃ max. inlet temp. 5.5 bar max. differential pressure (80 psid) at 25 ℃ 5.5 bar max. inlet pressure (80 psi) at 25 ℃ 80 psig max. inlet pressure
长度	8.2 cm (3.24 in.)
直径	6.9 cm (2.7 in.)
过滤面积	17.7 cm²
inlet connection diam.	3/4 in.
outlet connection diam.	1/4 in.
杂质	≤0.25 EU/mL (LAL test, Aqueous extraction)
基质	Durapore^®
孔径	0.22 μm nominal pore size 0.22 μm pore size
input	sample type liquid
bubble point	≥3450 mbar (50 psig), air with water at 23 ℃
配件	inlet sanitary flange 19 mm (3/4 in.) inlet sanitary flange outlet hose barb 6 mm (1/4 in.) outlet hose barb
运输	ambient

Optiscale® Capsule Filter Durapore®
