Conductive silver printing ink, resistivity 9-10 μΩ-cm

Conductive silver printing ink, resistivity 9-10 μΩ-cm

品牌
Sigma-Aldrich
货号
791881
包装型号
规格纯度
参考价格
1763.86 *本价格含增值税费
促销
服务
  • 原厂保证
  • 包邮
  • 增值税票
数量
-+
产品名称:
Conductive silver printing ink, resistivity 9-10 μΩ-cm
Screen printable silver paste
Dyesol DYAG100 conductive silver ink
产品介绍:

产品说明

一般描述

Sheet Resistivity is 3.6 - 4 mΩ / square / mil. (at a 180℃ cure temperature)

应用

Use this Conductive Silver Ink to achieve outstanding conductivity at low cure temperatures when printing on a variety of substrates, including glass and polyesters (PET/PEN) and ITO/FTO coated substrates.

This Conductive Silver Printing Ink provides outstanding conductivity at low cure temperatures. It provides extremely low resistance of printed conducting tracks, essential for the photovoltaic applications, and is a key enabler in plastic electronics such as DSSC; OPV; CdTe solar cells etc.,by providing lowest track resistances of printed current collectors.

The Conductive Silver Printing Ink is comprised of a mixture of pure silver particles and an organometallic silver compound in an organic medium. When printed on polyester films, and then heated to 160 - 180℃, the particles consolidate to form a chemically-welded, continuous metal track.

包装

10, 20 g in glass bottle

法律信息

Product of Dyesol®
Dyesol is a registered trademark of Greatcell Solar

基本信息

NACRESNA.23

产品性质

测定75-85% (Solids content)
质量水平100
形式paste (white)
体积电阻率 9-10 μΩ-cm
粘度9000-12000 mPa.s (at shear rate of 10 sec-1 at 25℃)

安全信息

象形图GHS07
警示用语:Warning
危险声明H315 - H319
预防措施声明P305 + P351 + P338
危险分类Eye Irrit. 2 - Skin Irrit. 2
储存分类代码10 - Combustible liquids
WGKWGK 3
闪点(F)174.2 °F
闪点(C)79 ℃
