产品说明

一般描述

Poly(3,4-ethylenedioxythiophene)-poly(styrenesulfonate) (PEDOT:PSS) is a conductive polymer that is formed by electropolymerizing 3,4-ethylenedioxythiophene in a solution of poly(styrenesulfonate) (PSS). PEDOT is doped with positive ions and PSS with negative ions. It is mainly used in organic electronics due to the properties, which include

• low band gap
• good optical properties
• high conductivity
• low redox potential
• easy processing
• tunable film forming ability

High-conductivity grade.

应用

PEDOT:PSS can be used as an electrode material with high mobility for charge carriers. It can be used for a wide range of energy based applications such as organic photovoltaics (OPV), dye sensitized solar cells (DSSCs), organic light emitting diodes (OLEDs), supercapacitors and biomedical sensors.
Orgacon^™ S315 is ready-to-use and made with conductive polymer PEDOT:PSS. Typical application processes are slot die, Meyer bar and gravure coating. It is particularly designed for optimal properties on PET and meet the requirements of several transparent electrodes applications as alternative to ITO.

• ITO substitution coating.
• ITO-free OPV.

• Surface electrical resistance (SER) at 90% VLT* (visual light transmission): 125 Ω/square.

*Typical properties on PET with bar coater. Thermal cured at 130 ℃/ 6 min. VLT according to ASTM D 1003, excludes substrate.

• Stability ratio R/R_0 (500 hr at 60 ℃, 95% RH) : 1.3.

包装

100 g in Sure/Seal™

制备说明

• Dilute with DI water or compatible solvent if needed.
• Pre-treated substrate with corona- or plasma treatment increase adhesion.

其他说明

• These additives have low water content (less than 100 ppm).
• Please handle under inert and moisture free environment (glove box).
• Keep containers tightly closed.
• Keep away from heat and ignition sources.
• Store in a cool and dry place.
• Avoid storing together with oxidizers.

法律信息

Orgacon is a trademark of Agfa-Gevaert N.V.

产品性质

质量水平	100
等级	high-conductivity grade
描述	Visual Light Transmission (VLT): ≥ 80%
形式	dispersion
浓度	0.5-1 wt. % (PEDOT: PSS in water)
薄层电阻	<200 Ω/sq (coating : 40μ wet, drying: 6 min 130℃)
pH范围	2 - 3.5
粘度	≤70 mPa.s(20 ℃)
储存温度	2-8℃
SMILES string	CC1=C2OCCOC2=C(C)S1.CCC(C3=CC=CC=C3)C.C[SO3-]

安全信息

象形图
警示用语：	Warning
危险声明	H315 - H319
预防措施声明	P264 - P280 - P302 + P352 - P305 + P351 + P338 - P332 + P313 - P337 + P313
危险分类	Eye Irrit. 2 - Skin Irrit. 2
储存分类代码	12 - Non Combustible Liquids
WGK	WGK 2
闪点(F)	Not applicable
闪点(C)	Not applicable
