产品说明
一般描述
Device Configuration: Cartridge
制备说明
Sterilization Method
10 autoclave cycles or SIP @ 126 °C for 30 min
Sanitization Protocol
30 min with hot water @ 80 °C
分析说明
Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥10 L
Gravimetric Extractables: after 24-h soak in water
法律信息
POLYGARD is a registered trademark of Merck KGaA, Darmstadt, Germany
基本信息
| eCl@ss | 32031690 |
产品性质
| 质量水平 | 400 |
| 物料 | polypropylene silicone seal |
| 特点 | hydrophilic |
| manufacturer/tradename | Polygard |
| 参数 | 4.8 bar max. differential pressure (70 psid) at 25 ℃ 4.8 bar max. inlet pressure (70 psi) at 25 ℃ |
| cartridge nominal length | 20 in. (50 cm) |
| 直径 | 7.0 cm (2.75 in.) |
| 杂质 | ≤0.5 EU/mL bacterial endotoxins (LAL test, Aqueous extraction) |
| gravimetric extractables | ≤50 mg |
| 孔径 | 5.0 μm nominal pore size 5.0 μm pore size |
| input | sample type liquid |
| cartridge code | Code 7 (2-226; O-rings w/locking-tabs) |
