Indium tin oxide coated glass slide, rectangular

氧化铟锡涂覆的矩形玻片

品牌
Sigma-Aldrich
CAS
50926-11-9
货号
576352
规格纯度
surface resistivity 70-100 Ω/sq, slide
参考价格
1510.13 *本价格含增值税费
促销
服务
  • 原厂保证
  • 包邮
  • 增值税票
数量
-+
产品名称:
50926-11-9
Indium tin oxide coated glass slide, rectangular
ITO
ITO coated slide, rectangular
氧化铟锡涂覆的矩形玻片
ITO 涂覆的矩形玻片
产品介绍:

产品说明

一般描述

Indium tin oxide (ITO) is widely used as transparent conducting oxides. Its major characteristics are electrical conductivity, optical transparency and the ease to be deposited as films.

应用

ITO cover slides may be used for closed digital microfluidic devices and as a transparent electrodes in display and other optoelectronic devices. Some other potential uses that have been reported are:

  • Eumelanin samples prepared on ITO covered glass substrates.
  • Interface windows of the liquid cell for optical beam deflection (OBD) sensing contain a 20-nm-thick indium tin oxide film.
  • Mesoporous TiO2 films were formed on ITO conductive glass substrates.

包装

10, 25 pkg in poly tube

物理属性

ITO 涂层厚度为 150-300Å。
在 300℃ 下保持 30 分钟或更长时间,电阻可增至高达 375Ω。

基本信息

线性分子式In2O3 · (SnO2)x
MDL编号MFCD00171662
PubChem化学物质编号24880854
NACRESNA.23

产品性质

表面电阻率 70-100 Ω/sq
长度 × 宽度 × 厚度75 mm × 25 mm × 1.1 mm
透射比>87%
折射率n20/D 1.517 (lit.)
SMILES stringO=[Sn]=O.O=[In]O[In]=O
InChI1S/2In.5O.Sn
InChI keyLNNWKAUHKIHCKO-UHFFFAOYSA-N

安全信息

储存分类代码13 - Non Combustible Solids
WGKWGK 3
闪点(F)Not applicable
闪点(C)Not applicable
个人防护装备dust mask type N95 (US), Eyeshields, Gloves
