4,4,7,7,12,12-octyl-7,12-dihydro- bis[methylidyne(3-oxo-methyl-1H indene-2,1(3H)-diylidene)]]bis-4H-thieno[2″,3″:1′,2′]indeno[5′,6′:5,6]-s-indaceno[1,2-b]thiophene

产品名称：

2239303-91-2
F-M
FTIC-C8C8M
4,4,7,7,12,12-octyl-7,12-dihydro- bis[methylidyne(3-oxo-methyl-1H indene-2,1(3H)-diylidene)]]bis-4H-thieno[2″,3″:1′,2′]indeno[5′,6′:5,6]-s-indaceno[1,2-b]thiophene

产品介绍：

产品说明

一般描述

Non-fullerene acceptors (NFAs) are currently a major focus of research in the development of bulk-heterojunction organic solar cells (OSCs). In contrast to the widely used fullerene acceptors (FAs), the optical properties and electronic energy levels of NFAs can be designed and readily tuned. NFA-based OSCs can also achieve greater thermal stability and photochemical stability, as well as longer device lifetimes, than their FA-based counterparts.Recent developments have led to a rapid increase in power conversion efficiencies for NFA OSCs, with values now exceeding 15% in a single junction cell, and >17% for a tandem cell, demonstrating the viability of using NFAs to replace FAs in next-generation high-performance OSCs.

应用

F-M is a non-fullerene acceptor that absorbs visible light, when used in a front cell paired with NIR absorbing rear cell, the resulted tandem organic solar cell gave a record energy conversion efficiency of 17.3%.

Tandem Cell Device performance:
ITO/ZnO/PFN-Br/PBDB-T:F-M/M-PEDOT/ZnO/PTB7- Th:O6T-4F:PC71BM/MoO₃/Ag
Voc=1.642 V
Jsc=14.35 mA/cm²
FF=73.7%
PCE=17.3%

基本信息

经验(实验)分子式	C₉₉H₁₂₂N₄O₂S₂
分子量	1464.18

产品性质

描述	Band gap: 1.72 eV Band gap: E_g = 1.72 eV Solubility: Soluble in Chloroform, CB and ODCB
测定	≥98%
形式	solid
轨道能量	HOMO -5.42 eV LUMO -3.70 eV

安全信息

储存分类代码	11 - Combustible Solids
WGK	WGK 3
闪点(F)	Not applicable
闪点(C)	Not applicable
