3D Printable Graphene Oxide Ink

品牌
Sigma-Aldrich
货号
916579
包装型号
规格纯度
参考价格
1293.44 *本价格含增值税费
促销
服务
  • 原厂保证
  • 包邮
  • 增值税票
数量
-+
产品名称:
3D Printable Graphene Oxide Ink
3D Printing graphene oxide ink
Direct extrusion printable graphene oxide ink
产品介绍:

产品说明

一般描述

We are committed to bringing you Greener Alternative Products, which adhere to one or more of The 12 Principles of Green Chemistry. This product has been enhanced for energy efficiency. Click here for more information.

应用

This product is a thixotropic ink based on graphene oxide (GO) nanosheets. It is suitable for various direct ink write (aka robocasting) printing technologies. The ink offers a stable dispersion of GO, high viscosity, good printability, and long shelf life. Freeze-dried and annealed patterns provide low electrical resistivity and high surface area. The ink is suitable for applications such as batteries, supercapacitors, electrocatalysis, etc.

制备说明

Before Printing:
Bring the ink to room temeprature, best to mix the ink in a planetary mixer before usage.

Printing:
Recommended 3D printing nozzle diameter size is 400 micron.

Post printing:
After 3D printing, this ink can be directly freeze-dried in liquid nitrogen and vacuum to obtain free- standing graphene oxide aerogel.
This ink can also be processed by adding gelling agents to enable a covalent bond established between the graphene oxide sheets. Gelation agents such as ammonium carbonate, ammonium hydroxide, resorcinol formaldehyde have all been reported to be sufficient. After gelation, the wet GO gels printed parts are washed in acetone to remove water from the pores. Supercritical CO2 can then be used to dry the GO gels.

Curing:
Parts that are printed with gelling agent can be cured in sealed glass vials at 85 ℃.
The dried aerogels are generally reduced to graphene aerogels by thermal treatment at 1050 ℃ under inert atmosphere. Other chemical reduction methods include hydrazine reduction, dried aerogels can also be reduced using hydroiodic acid, followed by washing in ethanol, water and then freeze drying.

储存及稳定性

Tighly seal remaining ink, and store in 2-8 ℃ fridge.

产品性质

质量水平100
描述Graphene oxide sheet size: 300-800 nm lateral size
Number of layer for graphene oxide: single layer
环保替代产品特性Design for Energy Efficiency
Learn more about the Principles of Green Chemistry.
浓度40 mg/mL (Graphene oxide aquous ink)
粘度100-210 Pa.s(25 ℃) (@ shear rate of 10 s-1)
环保替代产品分类Enabling
储存温度2-8℃

安全信息

储存分类代码10 - Combustible liquids
WGKWGK 3
